Specifications	HE-SEB-2100
Edge Profiles	Bevel / Flat & Arris / Pencil / OG
Glass Thickness	3 – 25 MM
No. Of Wheels	3 peripheral wheels or 1 cup wheel
Glass Exterior Diagonal	27’’ – 82’’  4-½’’ – 27’’ (with small suction cup platform)
Bevel Width	0-30 mm (1-1/8’’ )
Bevel Angle	3° – 20°
Table Rotating Speed	0 – 6.5 RPM
Table Rotating Adjustment	Hand wheel adjusted infinite speed regulator with high & low speeds main motor
Operation	Round or Close to Round – Automatic
Operation	Shape – Manual
Wheels Form	Peripheral – Flat & Arris / Pencil / Ogee
Wheels Form	Cup – Bevel
Wheel Size	Peripheral – OD 175, 150 or 100mm
Wheel Size	Cup – OD 150mm
Spindle Motors Power	0.85 / 1.1 kW ( High / Low Speed)
Water Pump Motor	AC 0.25 KW
Compress Air Pressure	8 MPA
Total Power	2.9 Kw
Voltage	230V AC / 3 phase / 60 HZ
Weight	1200 kg ( 2,640 pounds )
Outer Dimension	71’’ L x 75’’ W x 82’’ H
